Stainless hlau 314 1.4841
Cov Khoom Piav Qhia Cov tshuaj muaj pes tsawg leeg ntawm Stainless Steel 314 (1.4841) yog ib qho tseem ceeb uas qhia txog nws cov khoom thiab tsim nyog rau ntau yam kev siv. Nkag siab txog cov ntsiab lus tseeb ntawm cov hlau no yog qhov tseem ceeb rau cov engineers, metallurgists, thiab manufacturers ua ...
Hauj lwm lawm
Khoom Description
Tshuaj muaj pes tsawg leeg
| Element | % Tam sim no (hauv daim ntawv khoom) |
|---|---|
| Cov pa roj carbon (C) | 0.20 |
| Silicon (Si) | 1.50 - 2.50 |
| Manganese (Mn) | 2.00 |
| Phosphorus (P) | 0.045 |
| Sulfur (S) | 0.015 |
| Chromium (Cr) | 24.00 - 26.00 |
| Nickel (Ni) | 19.00 - 22.00 |
| Nitrogen (N) | 0.11 |
| Hlau (Fe) | Tshuav |
Mechanical zog (ntawm chav tsev kub nyob rau hauv annealed mob)
| Daim ntawv khoom | ||
|---|---|---|
| C, H, P | L | |
| Thickness ib los yog txoj kab uas hla d (mm) | tsawg dua los yog sib npaug li 12 | d Tsawg dua lossis sib npaug li 25 |
| Pov thawj muaj zog | Rp0.2 N/mm2 | 230 |
| Rp1.0 N/mm2 | 270 | |
| Tensile zog | Rm N/mm2 | 550 - 750 |
| HB. Max 1) 2) 3) | 223 |
Molybdenum, thaum tam sim no nyob rau hauv me me (txog 2.5%), txhim khu cov hlau tsis kam rau pitting thiab crevice corrosion, tshwj xeeb tshaj yog nyob rau hauv ib puag ncig hnyav. Tooj liab tuaj yeem txhim kho qhov tsis kam rau qee cov kua qaub thiab ua kom cov khoom siv thermal conductivity.
Kev sib xyaw ua ke thiab kev faib ua feem ntawm cov ntsiab lus hauv Stainless Steel 314 ua rau cov khoom siv nrog lub zog kub, zoo oxidation tsis kam, thiab zoo heev corrosion kuj. Qhov no ua rau nws tsim nyog rau cov ntawv thov hauv kev lag luam xws li cov khoom siv kho cua sov, cov khoom siv rau hauv cub tawg, kev ua lag luam petrochemical, thiab aerospace, qhov chaw uas nws raug kub hnyiab thiab corrosive.
Nws yog ib qho tseem ceeb kom nco ntsoov tias cov tshuaj muaj pes tsawg leeg ntawm Stainless Steel 314 yuav txawv me ntsis nyob ntawm seb cov qauv tsim tshwj xeeb thiab cov kev xav tau ntawm cov neeg siv kawg. Kev tswj kom raug thiab zoo ib yam ntawm cov muaj pes tsawg leeg thaum lub sij hawm tsim khoom yog qhov tseem ceeb los xyuas kom meej cov khoom xav tau thiab kev ua tau zoo ntawm cov khoom kawg.
Hauv cov ntsiab lus, cov tshuaj muaj pes tsawg leeg ntawm Stainless Steel 314 (1.4841) yog ib qho ua tib zoo sib npaug ntawm cov ntsiab lus uas sib sau ua ke nrog nws cov khoom zoo tshaj plaws, ua rau nws yog ib qho khoom muaj txiaj ntsig hauv ntau daim ntawv thov kev lag luam.
