S10c hlau
Nov yog cov ntaub ntawv tshwj xeeb rau S10C steel: • Chemical Composition: • Carbon (C): 0.08% - 0.13%. • Silicon (Si): 0.15% - 0.35%. • Manganese (Mn): 0.30% - 0.60%. • Sulfur (S): Tsawg dua lossis sib npaug li 0.030%. • Phosphorus (P): Tsawg dua lossis sib npaug li 0.030%. • Chromium (Cr): Tsawg dua lossis sib npaug li 0.20%. • Nickel...
Hauj lwm lawm
Khoom Description
• S10C steel: Tshuaj muaj pes tsawg leeg:
• Carbon (C): 0.08% - 0.13%.
• Silicon (Si): 0.15% - 0.35%.
• Manganese (Mn): 0.30% - 0.60%.
• Sulfur (S): Tsawg dua lossis sib npaug rau 0.030%.
• Phosphorus (P): Tsawg dua lossis sib npaug rau 0.030%.
• Chromium (Cr): Tsawg dua lossis sib npaug rau 0.20%.
• Nickel (Ni): Tsawg dua lossis sib npaug rau 0.25%.
• Copper (Cu): Tsawg dua lossis sib npaug rau 0.30%.
• Mechanical Properties:
• Tensile zog: kwv yees li 372 - 470 MPa.
• Yield zog: Nyob ib ncig ntawm 205 - 235 MPa.
• Elongation: 25% - 35%.
• Hardness: 121 - 156 HB.
• Quenching:
• Cua sov kub rau quenching feem ntau yog nyob ib ncig ntawm 800 - 850 degree .
• Qhov nruab nrab quenching tuaj yeem yog dej lossis roj. Vim nws cov ntsiab lus carbon tsawg, lub hardenability yog txwv. Tom qab quenching, tempering yuav ua tau ntawm qhov kub thiab txias kom txo brittleness thiab txhim kho toughness.
S10C steel yog cov pa roj carbon steel nrog cov yam ntxwv tshwj xeeb thiab pom kev siv dav hauv ntau qhov chaw.
Hauv kev lag luam tsim khoom, S10C steel feem ntau yog siv los ua cov khoom me me. Nws cov machinability zoo tso cai rau kev ua haujlwm yooj yim rau hauv cov duab thiab qhov ntau thiab tsawg. Piv txwv li, nws tuaj yeem siv los tsim cov ntsia hlau, ceev, thiab bolts. Lub zog nruab nrab thiab ductility ntawm S10C steel ua rau cov khoom no txhim khu kev qha thiab muaj peev xwm tiv taus qee qhov kev ntxhov siab.
Hauv kev lag luam tsheb, S10C steel tuaj yeem pom nyob rau hauv qee yam tsis tseem ceeb. Nws tuaj yeem siv rau qhov chaw uas tsis tas yuav muaj lub zog siab heev tab sis yuav tsum muaj cov qauv zoo thiab ua haujlwm ntev. Piv txwv li, nws tuaj yeem siv rau qee qhov kev sib txuas lossis kev txhawb nqa hauv lub tsheb.
Hauv kev tsim cov cuab yeej, S10C steel tuaj yeem ua haujlwm los ua cov cuab yeej yooj yim. Nws kuj tsis tshua muaj hardness piv rau ib co high-carbon steels ua rau nws yooj yim rau sharpen thiab tswj. Cov cuab yeej ua los ntawm S10C steel yog tsim rau cov dej num uas tsis cuam tshuam nrog kev txiav hnyav lossis hnyav hnyav.
S10C steel kuj tseem siv los tsim qee yam khoom siv hauv tsev. Vim nws pheej yig thiab yooj yim ntawm kev ua, nws tuaj yeem siv los ua cov khoom siv lossis cov rooj tog zaum. Piv txwv li, nws tuaj yeem siv rau tes lossis pob qhov rooj.
Hauv kev xaus, S10C steel, nrog nws cov tshuaj muaj pes tsawg leeg thiab cov khoom siv kho tshuab, muaj ntau yam kev siv hauv kev lag luam sib txawv. Nws cov machinability zoo, nruab nrab lub zog, thiab ductility ua rau nws yog ib qho kev xaiv tsim nyog rau kev tsim khoom me me, cov khoom siv tsheb, cov cuab yeej, thiab cov khoom siv hauv tsev. Txawm hais tias nws cov kev txwv ntawm lub zog piv rau lwm cov hlau, nws tseem ua lub luag haujlwm tseem ceeb hauv ntau daim ntawv thov uas tus nqi-zoo thiab kev ua haujlwm yooj yim yog qhov tseem ceeb.
