Qib 1060 Steel
Cov Khoom Piav Qhia Kev Sib Txuas-wise, nws yog tsim los ntawm hlau thiab carbon, nrog cov ntsiab lus carbon ntawm kwv yees li 0.60%. Nrog rau cov pa roj carbon, nws muaj me me ntawm manganese, silicon, thiab lwm yam alloying ntsiab uas ua lub luag haujlwm tseem ceeb hauv kev txiav txim siab nws cov khoom. Nyob rau hauv cov nqe lus ntawm ...
Hauj lwm lawm
Khoom Description
1060 Steel Chemical Composition
| Lub ntsiab | Cov ntsiab lus (%) |
|---|---|
| Hlau, Fe | 98.35-98.85 |
| Manganese, Mn | 0.60-0.90 |
| Carbon, C | 0.55-0.660 |
| Sulfur, S | Tsawg dua lossis sib npaug rau 0.050 |
| Phosphorus, P | Tsawg dua lossis sib npaug rau 0.040 |
Lub cev muaj zog
| Cov khoom | Metric | Imperial |
|---|---|---|
| Qhov ntom | 7.85 g / cm²3 | 0.284 lb/in3 |
| Melting point | 1510ºC | 2750ºF |
Mechanical Properties
| Cov khoom | Metric | Imperial |
|---|---|---|
| Tensile zog, qhov kawg | 620 MPa rau | 8 9900 psi |
| Tensile zog, tawm los | 485 MPa ua | 70 300 psi |
| Modulus ntawm elasticity | 190-210 GPa | 29700-30458 tsi |
| Bulk modulus (tseem ceeb rau steel) | 140 GPa | 20 300 TZS |
| Shear modulus (zoo rau steel) | 80 gpa ua | 11 600 ksg |
| Poissons ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation ntawm tawg (hauv 50 mm) | 10% | 10% |
| Kev txo qis ntawm cheeb tsam | 45% | 45% |
| Hardness, Brinell | 183 | 183 |
| Hardness, Knoop (hloov los ntawm Brinell hardness) | 204 | 204 |
| Hardness, Rockwell B (hloov los ntawm Brinell hardness) | 89 | 89 |
| Hardness, Vickers (hloov los ntawm Brinell hardness) | 192 | 192 |
Qib 1060 Steel pom kev siv dav hauv ntau yam kev lag luam. Nws yog feem ntau siv rau hauv kev tsim cov springs, hlau ropes, shafts, thiab lwm yam mechanical Cheebtsam uas yuav tsum tau ib tug ua ke ntawm lub zog, durability, thiab formability. Tsis tas li ntawd, nws kuj yog siv rau hauv kev tsim kho kev lag luam rau kev tsim qauv.
Hauv kev xaus, Qib 1060 Steel yog cov khoom siv ntau yam thiab txhim khu kev qha uas muaj kev sib txuam zoo ntawm cov khoom siv kho tshuab thiab cov yam ntxwv ua haujlwm. Nws txoj kev siv dav hauv ntau qhov chaw yog qhov ua pov thawj rau nws qhov ua tau zoo thiab muaj peev xwm ua tau zoo.
